Delta D88 Retaining Grade High Temperature Adhesive 50ml Green

Be the first to review this product

SKU: 539819 | EAN: 5060811740347
£15.50 £12.92
In Stock -
- +

The Delta D88 Retaining Grade High Temperature Adhesive 50ml Green is a low viscosity, high strength retaining adhesive ideal for permanently bonding engineering assemblies together.

Delta D88 Retaining Grade High Temperature Adhesive 50ml Green

£12.92

Overview

The Delta D88 Retaining Grade High Temperature Adhesive 50ml Green is a low viscosity, high strength retaining adhesive ideal for permanently bonding engineering assemblies together.

This adhesive has a higher temperature than other anaerobic compounds making it perfect for areas where heat build up is common.

For best results clean all the surfaces (external and internal) with D406 Surface Prep Cleaner and allow all solvent to completely evaporate. If the material is inactive metal or the cure speed is too slow spray with Anaerobic Activator D405 and allow to dry.

When working with Slip Fitted Assemblies apply adhesive around the leading edge of the pin and the inside of the collar and use a rotating motion during assembly to ensure good coverage.

Press Fitted Assemblies require adhesive to be applied thoroughly to bond surfaces and assemble at high press on rates.

For Shrink Fitted Assemblies the adhesive should be coated onto the pin, the collar should then be heated to create sufficient clearance for free assembly.  Parts should not be disturbed until sufficient handling strength is achieved.

Disassembly should be done by applying localized heat to the assembly to approximately 250C and disassemble while hot.

Features

  • High temperature resistant

  • Anaerobic

  • Low viscosity

  • 50ml

  • Green Colour





Specifications

  • Size: 50ml
  • Colour: Green
  • Service Temperature Range: -55°C to +200°C
  • Composition: Urethane Methacrylate
  • Viscosity: 640 cps at 25oC
  • Specific Gravity: 1.20
  • Flash Point: >93oC
  • Shelf Life: 1 year
  • vHealing Cure Time: 60 minutes
  • Functional Cure Time: 3 - 4 hours
  • Full Cure Time: 24 hours
  • Compressive Shear Strength, ISO 10123: After 24 hours at 22oC Steel Pins & Collars >22 N/mm2 > 3,150 psi After 30 minutes at 22oC Steel pins & Collars 11 N/mm2 1,595 psi
  • Breakaway Torque: MIL-S-46163 20 to 40 N.m. 175 to 350 Ib.in.
  • Prevail Torque: MIL-S-46163 30 to 60 N.m. 265 to 530 Ib.in.

Recommended For Use

  • Assembly
  • Pipe Fitting
